Engineering Drawing Lines
WorkForge
Updated Apr 28, 2025
What you'll learn
- Identify each type of line used in an engineering drawing
- Describe the function of three line types used in an engineering drawing: visible, hidden, and center
- Describe the function of line precedence
- Identify line types given an engineering drawing
- Interpret hidden features on an engineering drawing
- Interpret views from viewing planes
Course DescriptionThere are many types of lines used to define the shape of an object on an engineering drawing. Each type has a specific function in the definition of the object.
